Micro Rod Lens Cylindrical Endoscopes Grin Glasses Lens Optical Rod Lens
| Feature | Micro Rod Lens / Optical Rod Lens | Grin Glasses Lens |
|---|---|---|
| Material Substrate | N-BK7, Fused Silica, or Sapphire | Gradient Index Doped Glass |
| Diameter Range | 0.2mm to 10.0mm | 0.5mm to 3.0mm |
| Length Tolerance | ±0.01mm to ±0.05mm | ±0.02mm |
| Surface Quality | 20-10 to 10-5 Scratch-Dig | 40-20 Scratch-Dig |
| Refractive Profile | Constant (Homogeneous) | Parabolic (Gradient Index) |
| End Face Flatness | λ/4 to λ/10 @ 633nm | λ/2 @ 633nm |
| Angular Precision | < 1 arc minute | N/A (Internal Gradients) |
| Application | Cylindrical Endoscopes Relays | Micro Rod Lens Objectives |
| Parameter | Specification Range |
|---|---|
| Range of diameter | Dia.0.7mm-Dia.400mm |
| Range of curve radius | R1.5-R∞ etc |
| Tolerance of diameter | +/-0.1, +/-0.01, +/-0.005 etc. |
| Surface of diameter | λ, 1/2λ, 1/4λ, 1/10λ etc |
| Tolerance of Thickness | +/-0.1, +/-0.05, +/-0.01 etc |
| Centration | +/-2', +/-1' etc |
| Aperture N | 5, 1 etc |
| Irregularity ΔN | 2, 1, 0.5, 0.2 etc |
| Surface quality | 60/40, 40/20, 20/10, 10/5 etc |
- Medical Endoscopy: Using the Micro Rod Lens in arthroscopes, cystoscopes, and laparoscopes for high-resolution internal imaging.
- Industrial Borescopes: Deploying the Optical Rod Lens for inspecting aircraft engines and narrow piping systems.
- Fiber Optic Coupling: Utilizing the Grin Glasses Lens to focus light from laser diodes into single-mode fibers.
- Micro-Robotics: Integrating the Micro Rod Lens and Grin Glasses Lens into miniature robotic vision systems for precision tasks.
-
Sapphire Crystal Cylindrical Lens Projection Equipment Lens
Sapphire Crystal Cylindrical Lens Projection Equipment Lens The production of a Sapphire Crystal Cylindrical Lens involves sophisticated diamond-turning and polishing processes to manage the material's Mohs 9 hardness. This ensures that the Projection Equipment Lens achieves a pristine surface quality, which is vital for minimizing light scatter and maximizing the contrast ratio of the Projection Equipment. Because Sapphire Crystal has a broad transmission range from the
-
Convex Lens BK7 Optical Glass Cylindrical Plano Convex Lens For Optical Instruments
Convex Lens BK7 Optical Glass Cylindrical Plano Convex Lens For Optical Instruments In the field of high-precision optics, the Convex Lens BK7 Optical Glass series is recognized as a fundamental component for advanced light manipulation. Specifically, the Cylindrical Plano Convex Lens is designed to focus light into a sharp, uniform line rather than a single point, making it an essential optic for various scanning and alignment systems. By utilizing premium BK7 Optical Glass
-
Плоская выпуклая цилиндрическая инфракрасная лазерная коллиматорная линза
Plano Convex Cylindrical Infrared Laser Collimator Lens Product Overview The manufacturing process for a Plano Convex Cylindrical Infrared Laser Collimator Lens requires advanced CNC grinding and diamond turning to achieve the necessary surface accuracy. Because Infrared Laser systems are highly sensitive to thermal lensing and material absorption, the Plano Convex Cylindrical substrate must be chosen for its specific refractive index and low absorption coefficient. As a
